Wireless CNC manual pulse generator - 1PCĪpplication: CNC MPG XHC-HB03 is a machine tool accessory product designed for NC Studio PM53C 53B Weihong Controller. With the CNC MPG, you can be very close to the spindle and set the origin accurately.įull Set CNC MPG for NC Studio PM53C Weihong Controller is Consisted By Following Parts: If without the CNC MPG, we must do origin setting by the computer, result is that we cannot see clearly the z position because computer will have a distance with cnc machine while the CNC pendant optimizes this operation. As every cnc operator friend knows, when do z zero setting, we have to be very close to the router cutters on spindle to see clearly so we can set z origin accurately. It makes the zero point setting operation more convenient.

CNC USB CONTROLLER PENDANT GENERATOR

XHC HB03 is a wireless manual pulse generator for nc studio weihong controller PM53C.

CNC MPG is also known as name of CNC pendant. Ordered the xpro v5 and am impressed with the quality of the product going to be adding to my longmill this weekend.Brief: this product is CNC MPG model. I couldn't be happier with the CNC xPRO V5. It doesn't come with any documentation but as others have said, all information about this unit can be found on the Github page. I also love that the fan on this controller is whisper quiet. After hooking everything up and opening up CNCjs, I was able to manually jog every axis in literally seconds and ran my first program within a few minutes. This thing works great right out of the box! I'm using it to control my Nema 17 powered router with CNCjs. Still figuring out the macros but the Z is working great. Mike from Spark was great to work with to get the first unit replaced as it stopped working during setup but the 2nd one has been running now for a couple of weeks and no issues at all. The motors are way quieter, more functionality and much smaller footprint. Way better than the stock controller that came with my 4030. Only thing I would love to have in addition is an option to control one more mortar. I hope they keep this product line going. Mike was help fun answering questions and today I found they have the firmware source code also available. I have dual motor Y axis CNC from SainSmart 4030xl and xPro s Y axis homing with alignment( squaring ) feature saves lot of headaches. Works with induction limit switches and 24V power is plus.

CNC USB CONTROLLER PENDANT DRIVERS

Trinamic drivers are smooth, efficient and much more configurable. Well designed compact controller loaded with enhancements compared to the units you get with the CNC hardware. Spark concepts reached out to me offering any help that I might need I look forward to working with them in the future.

I will be using this with my Long Mill and my second home built machine. I am planning on hooking up this weekend. I'm very impressed with quality and pkging. It is living up to all the documentation no complaints Have yet to finish setting it up, but Mark has been super helpful, excites for what this controller can do! Posted by Preston Landon on 19th Sep 2021 Documentation:įor user guides, hook-up instructions and all other documentation please check out the CNC xPRO V5 Github repository. As such, the xPRO V5 can be used with most current GRBL senders and post-processors. Note: The xPRO V5 runs a 32bit port of the GRBL.

Vetric Vcarve or Aspire depending on design (drawing and CAM, includes GRBL postprocessor) (paid).

XPRO V5 WebUI (or CNCjs for USB mode (free/opensource))įor artwork (think signs, drawings, plaques, awards, etc):.

Fusion 360 (both CAD design and CAM, includes GRBL postprocesser by default) (free for hobbyists).

The xPRO comes fully assembled and programmed so all you need to do is wire up your motors and start cutting! The xPRO V5 is defaulted to support dual Y machines, or XYYZ, machines with motor current of 2.8A.įrom the computer side we have found that CNCjs Desktop is amazing and packed with great features! (open source / free download).įor designing parts here at Spark Concepts we use the following stacks:įor mechanical parts (think gantry plates, mounts, boxes, etc):

Selectable limit switch voltage (5V or 24v).

CNC USB CONTROLLER PENDANT SOFTWARE

4 software defined, independent motor drivers can:.

Built-in Heatsink & Temperature Controlled Cooling Fan.

USB-C interface work with GRBL sender programs.

Sleek Web Interface with cut-from-SD capability (SD card included).

High Power 6A stepper drivers based on the Trinamic TMC5160.

CNC USB CONTROLLER PENDANT 32 BIT

The xPRO V5 is the most advanced GRBL based motion controller in the World! Our plug and play xPRO V5 brings you the advanced stepping and power of Trianamic drivers along with Wifi and USB interfaces, all powered by a 32 bit processor and wrapped in a beautiful ABS case (with integrated cooling).
